Thermoforming Machine

2.1OG-MS780-680 Three Station Positive and Nagative Pressure thermoforming Machine, it is a new generation evolutionary product for packaging industry, food industry and electronic industry, which is newly developed by our company with German technology. This series of widely used, good versatility, according to customer requirements, can fully be applied to all product requirements.
2.2OG series high speed forming machines are running at high speed, low noise, and low energy consumption environment, its reliability, operation and maintenance is absolutely reliable.
2.3The thermoforming machine with speed up to 30 times/min is definitely called high speed thermoforming machine. All adopt absolute servo control system, coupled with advanced automation system, to process starch degradation sheet, photodegradation sheet, environmental protection sheet, PP, PS, PET, PVC, high-speed thermoforming machine are impeccable.
2.4With the new design of mould changing mechanism, to ensure a very short mould replacement time, according to the human efficiency optimization design of the simple mould changing system, as well as the steel knife punching and stacking device, to ensure the Max. production time.
3.Features Introduced
3.1It is a mechanical-electrical system combined with mechanical, pneumatic, electrical integration. PLC programming, touching screen, operation simple.
3.2Positive and negative pressure forming.
3.3Five fulcrum structure, upper and lower mould forming method.
3.4Stretching Servo.
3.5Feeding Servo, Length stepless adjustment, high speed, accurate and stable.
3.6Upper and lower electric heating furnace with 4 pcs of heating zones.
3.7The temperature control system of electric heating furnace adopts computer intelligent automatic compensation control, which has the advantages of high precision of fine tuning, uniform temperature, stable and not affected by external voltage, low energy consumption (about 15% energy saving), long service life of furnace plate and so on.
3.8 Forming, mould opening of cutting, mould closing is controlled by servo motor, and products are automatic counting output.
3.9Products are stacked downward.
3.10With product data and parameter file memory function.
3.11The width of the feed chain rail can be adjusted synchronously automatically or separately electrically.
3.12Electric heating furnace automatic removal device.
3.13Mechanical loading and winding device, reduce the labor intensity of workers.

---
